Instanta 3-5Ltr SureFlow Compact Boiler
Buy for £599.91
£719.89 Including VAT
If you need any help or advice choosing the right machine please call us on: 0870 774 8111
Where space is limited but standards are high
The SureFlow Compact CTS3 and CTS5 may be small, but they’re made to the same exacting specification as all Instanta’s boilers. These compact units have been specially designed to offer smaller catering establishments the ideal boiling water solution.
Features and Benefits
· Self diagnostics system
· Long-life incoloy element
· Well insulated for minimal heat loss & energy use
· Stainless steel drip tray included
· Complete with 1.75 metres of cable & 13 amp plug
Installation
Easy to install on a stable worktop.
Plumbing
Designed for direct connection to a potable cold water supply using the 1.5 metre (3/4” BSP) hose supplied. An isolating valve should be installed between the supply and the heater. Rear supply connection and choice of rear or front overflow is available (rear option requires kit not supplied).
Electrical
To be connected to 230 volt supply with a suitable break capacity.
Construction
Mirror finished stainless steel case.
Stainless steel heating chamber.
Low voltage switching.
Two safety cut-outs.
Approvals
WRAS approved.
Product Specifications
| Product | 3Ltr SureFlow Compact | 5Ltr SureFlow Compact |
|---|---|---|
| Product Code | CTS3 | CTS5 |
| Dimensions (HxWxD) | 400 x 218 x 465mm | 440 x 218 x 465mm |
| Tap Height | 150mm | 150mm |
| Rear Clearance | 50mm | 50mm |
| Weight | 11.5kg | 12kg |
| Power loading | 2.25kW | 3kW |
| Heat-up time | 13mins | 16mins |
| Recovery Rate | 0.37Ltr | 0.5Ltr |
| Stand by Power | 0.066kW/h | 0.066kW/h |
| Rapid Draw-Off | 3 Litres | 5 Litres |
| Litres Per Hour | 20 Litres | 30 Litres |
| Cups Per Hour | 120 | 162 |
